<a href=products.htm>HENSEL(KV) Distribution Boards and enclosures</a><BR>
A range of thermoplastic enclosures to IP 41 and IP 65 with transparent doors. Sizes available are 3, 4, 6, 9, 12, 18, 24, 36 (2 row), 36 (3 row), 48 and 54 modules. Advantages to the contractor are: 1 . Accessibility 2. Well designed, removable neutral and earth bars. 3. Neutral bars are splittable as standard. 4.Two formats facilitate the use of both din rail mounted accessories: i.e., M.C.B's/R.C.D's and bigger frame size plate mounted accessories: i.e., M.C.C.B's and contactors.
HENSEL Cable Junction Boxes
IP 65 cable junction boxes from 2.5mm2 to 240mm2 for applications where a high degree of sealing is required. Standard terminal blocks are five pole and can be mounted horizontally, vertically, diagonally or offset. Smaller size boxes to IP 54 with membrane entries facilitate the use of both flat and round cables without the need for glands. Special multi- terminal boxes up to 23 pole are also available. Boxes can also be supplied without terminals. Units come complete with stainless steel lid screws, IP 54 glands and a template for fixing holes. The range also includes boxes specifically for use in aggressive atmospheres.
HENSEL (Mi)
A modular Polycarbonate enclosure system to IP 65, available with either transparent or opaque front covers. A full range of accessories is included allowing a huge amount of flexibility. The enclosures are also ideal individually for din-rail mounted or plate mounted accessories with various options on front plates, hinged flaps and doors. The robust nature of the system makes it suitable for use in the toughest of environments. Enclosure sizes range from 150 x 300mm to 600 x 600mm.
HENSEL (Varitec)
Modular Distribution / Enclosure System (Metal) A modular metal distribution/enclosure system suitable for installations up to 160A. Protection class 1. Degree of protection = IP41. The modular cabinet structure allows the flexibility of being able to extend in any direction. The system design provides spacers to size the enclosures to fit neatly from ceiling to floor. In a multi-storey building installation. cables can be carried from floor to floor through these enclosures, without the need for trunking or other types of mechanical protection. Wiring is made easier and quicker without the obstruction of cabinet walls during assembly.
.
PALAZZOLI Industrial Plugs & Sockets EN 60309.1/2 (CEE 17-IEC 309)
16, 32, 63 and 125Amp in 2, 3 and 4 Pole plus Earth configurations. low voltage (20/25-40/50 Volt). Reinforced Polyamide construction. Colour coded with Keyway/Earth Pin position to ensure that only compatible items can be connected. Units are available in two degrees of protection IP 44 and IP 67. Other items including higher amperages i.e. 200A + (Non EN 60609) are also available.
PALAZZOLI Interlocked Switched and Protected Socket Outlets
16, 32, 63 and 125Amp interlocked switched sockets. The mechanical interlocking device prevents the unit from being switched on until the plug is inserted and will not allow removal of the plug until the switch is in the "off" position. Units featuring electrical interlocking are also available. Earth leakage and overcurrent protection or both is possible. Units are available in either Thermosetting Duroplast or Aluminium. Duroplast to IP 65. Aluminium to IP 55.
PALAZZOLI TER Series.
Protected Sockets and Combination Units A modular system allowing various options in distribution and circuit protection. Units can be surface or flush mounted, IP 44 and IP 55. Self extinguishing "Halogen Free" Thermoplastic construction. Modular low voltage sockets with integral transformers are included in the range. The Palazzoli range also includes switchgear, enclosures and light fittings to marine standard.
Residual Current Circuit Breakers and Enclosures
R.C.D's, 2 & 4 pole. 25, 40, 63, 80, 100 and 125 Amps with 30, 100, 300 and 500 mA sensitivity. (2 pole) in 2 module format. A full range of R.C.D / M.C.B. Combination units R.C.B.O.'s to BSEN 61009 are included in the range. A complimentary range of plastic and metal enclosures are also available ex- stock.
Miniature Circuit Breakers
M.C.B.'s from .5 - 63 Amps. 1, 2, 3 and 4 pole. Rated at 1 OkA. B, C and D curves available. Manufactured in Germany by Doepke to comply with the highest European standards. Auxiliary contacts and accessories available ex-stock U.K. To BSEN 60898. Other din rail mounted accessories include isolators, timers, transformers, contactors, relays etc.
Busbar Wiring System
1, 2, 3 and 4 pole Miniature Busbars to link M.C.B's and other DIN rail mounted accessories. Various types including bars which allow spaces for auxiliary contacts, etc. Terminals for additional connections are also available. We provide a design / build service utilising our principal products and included in that service, modification of standard items from the following product types to suit specific application requirements:
<a href=special.htm>Special Build Combination Units</a><BR>
We provide a design / build service utilising our principal products and included in that service, modification of standard items from the following product types to suit specific application requirements
<a href=special.htm#industrial>Industrial Switch & Fusegear</a><BR>
Isolators from 25A-2000 Amps. Switchfuses from 25A-630 Amps. Changeover Switches 63A4000 Amps. Bypass Switches 63A4000 Amps. Motorised Changeover Switches 300A-4000 Amps. We also supply a full range of accessories I.E. auxiliary contacts, fuses etc. Units can be supplied either enclosed or in open format for panel mounting. Enclosure types vary, depending on your requirement, up to IP 65.
<a href=special.htm#control>Control Gear</a><BR>
Contactors, Starters, Push buttons, Indicator lights, Key switches, Relays etc.
<a href=special.htm#isolators>Isolators / Safety Switches</a><BR>
A complete range of isolators available in ratings from 16 - 800 Amps. 3 & 6 Pole.
Auxiliary contacts and other accessories are also available.
<a href=special.htm#custom>Special Build Combination Units</a><BR>
We have in-house facilities to design and build combination units and distribution boards to suit a multitude of applications. From standard Caravan Park and Marina units with high IP rating requirements to distribution and control units designed for use in specialised high technology situations, the telecommunications industry being an ideal example. The team members at ADEA draw on a wealth of technical knowledge and personal experience of this segment of the Electrical Industry, which enables us to provide this extremely successful service. We see ourselves not just as Distributors but as Problem Solvers, a reputation which has won for us high profile contracts normally only enjoyed by more established Companies. Pre-wired distribution unit. Control Equipment to your specification. Metered Caravan Park unit. Pre-wired mains failure change-over units.
<a href=contact.htm>Contact us</a><BR>
Alan Doyle Electrical Agencies Unit 11 Hither Green Industrial Estate Clevedon North Somerset BS21 6XU Tel: +44(0)1275 872800 Fax: +44(0)1275 872810
